AWS Cloud Support Internship: Mastering Troubleshooting and Architecture

Context: Summer 2025 AWS Cloud Support Associate internship in Seattle (Oscar building). My cohort lived inside labs, mock tickets, and certification prep—no direct customer production support.
AI assist: ChatGPT + Amazon Q Business helped summarize service docs and draft troubleshooting checklists; I edited everything before submitting to mentors.
Status: Honest reflection so recruiters see exactly what I touched (and what remains on the “practice only” list).

Reality snapshot

• 12-week program split between mornings (Cloud Practitioner/SAA coursework, architecture reviews) and afternoons (ticket simulations, hands-on labs, runbook writing).
• I rotated through EC2, S3, IAM, networking, and observability labs; each lab ended with a quiz + short retro shared with a senior engineer.
• Capstone was a media metadata pipeline built entirely in AWS sandbox accounts: S3 → Lambda (FFmpeg) → DynamoDB → API Gateway + static dashboard. No external users relied on it.
• Tracked lab completion, quiz scores, ticket MTTR in simulations, and budget alerts; shipped weekly retros (“what broke / what I fixed / what I still don’t know”) to mentors.

Table of contents

• Weekly structure
• Troubleshooting drills I ran
• Capstone: media metadata pipeline
• Tooling & automations I leaned on
• Proof & artifacts
• Gaps & next steps
• Interview stories I reuse

Weekly structure

Troubleshooting drills I ran

• EC2 boot loops: Collected console output, diffed failed user-data scripts, rebuilt launch templates. Lesson: user-data must be idempotent, and CloudWatch agent config drifts silently.
• VPC reachability: Reachability Analyzer + traceroute inside bastions; caught mismatched CIDRs and missing return routes during peering labs.
• S3 “Access Denied” mazes: IAM Policy Simulator + CloudTrail to isolate missing Principal/Condition in cross-account bucket policies; wrote a step-by-step playbook.
• Cost spikes: “Rapid response” checklist: Budgets alert → Cost Explorer by service → orphaned EBS + idle NAT → snapshot/terminate → tag everything.
• CloudWatch log flooding: Temporary retention policy, metric filters for error bursts, and alarms to detect runaway debug logs.
• Bedrock prompt logging: Prototyped logging wrapper to capture prompts/outputs for audit; documented privacy/legal considerations before any production use.

Capstone: media metadata pipeline (lab-only)

Architecture

• Input: Files land in media-ingest-bucket.
• Processing: Node.js 20 Lambda pulls the object, shells out to FFmpeg to extract metadata, pushes a compact JSON doc to DynamoDB.
• API: API Gateway exposes read-only endpoints so a static dashboard (S3 + CloudFront) can query the table.
• Observability: CloudWatch logs, metrics, and alarms track Lambda duration, DynamoDB throttle counts, and FFmpeg exits. Budgets/Cost Explorer alerts guard the lab account.

Resources:
  MediaBucket:
    Type: AWS::S3::Bucket
    Properties:
      NotificationConfiguration:
        LambdaConfigurations:
          - Event: s3:ObjectCreated:*
            Function: !GetAtt MetadataLambda.Arn

  MetadataLambda:
    Type: AWS::Lambda::Function
    Properties:
      Runtime: nodejs20.x
      Handler: index.handler
      Code:
        S3Bucket: !Ref ArtifactBucket
        S3Key: lambda.zip
      Environment:
        Variables:
          TABLE_NAME: !Ref MetadataTable

  MetadataTable:
    Type: AWS::DynamoDB::Table
    Properties:
      BillingMode: PAY_PER_REQUEST
      AttributeDefinitions:
        - AttributeName: FileKey
          AttributeType: S
      KeySchema:
        - AttributeName: FileKey
          KeyType: HASH

What worked

• Lambda stayed under 2 GB memory/30 s duration even when FFmpeg processed 250 MB sample files.
• DynamoDB recorded ~300 sample rows with zero throttling thanks to on-demand mode.
• CloudWatch dashboard (latency, invocations, FFmpeg exit codes, DynamoDB consumed RCUs) made it easy to talk through the design review.
• Step Functions “stretch goal” doc lists how I’d fan-out enrichment jobs if this ever handled more than demo traffic.

What still needs work

• Replace API key auth with Cognito + IAM authorizers (on the backlog).
• Integration tests exist locally but CI/CD only runs lint + unit tests. Need to script sam validate, deploy to a staging stack, and capture screenshots automatically.
• FFmpeg binary came from a public layer; I owe the team a security review and pinning strategy before recommending it anywhere else.
• Add signed URLs and lifecycle rules on the ingest bucket so lab data ages out automatically.
• Improve cold-starts: explore container-based Lambda vs. slimmer FFmpeg layer; measure impact and document trade-offs.
• Load test with varied media types and longer runs; current numbers are from small samples.

Tooling & automations I leaned on

• Docs-as-code: Every lab ended with a markdown runbook + diagram (Mermaid + Excalidraw). These live in notes/aws-internship/ and were reviewed by mentors weekly.
• Cost visibility: Budgets (email + Slack) triggered at 10% and 25% of the sandbox allowance, mostly to prove I could wire alerts.
• Security workflows: npm audit CI (both frontend + backend), OWASP ZAP baseline workflow for the Render-deployed intern app, Bedrock prompt logging experiments with Amazon Q.
• AI helpers: Amazon Q Business answered “where does this service log?” while ChatGPT helped translate dense docs into playbooks. Every AI-assisted snippet is annotated in the repo so it’s obvious what I edited.
• Observability kits: Reusable CloudWatch dashboards for EC2/Lambda/RDS; alarm templates for errors, latency p90/p99, throttles.
• Runbook template: Intro → Symptoms → Timeline → Logs/metrics links → Fix → Prevent → Open questions. Kept consistency across labs.
• Retro cadence: Weekly self-review to mentors: “what worked, what broke, what I still don’t understand,” with ticket IDs and lab links.

Proof & artifacts

• Lab tracker: https://github.com/BradleyMatera/aws-internship-journal (private; screenshots/redacted excerpts available).
• Dashboards: dashboards/cloudwatch-dashboard.json plus PNG exports in the repo.
• Runbooks: See notes/runbooks/*.md—each links to the relevant log groups, budgets, or config files.
• Capstone deck: PDF stored under presentations/capstone-media-pipeline.pdf with the architecture diagram, metrics, and TODO table.
• Quizzes/assessments: Scores + notes per module; gaps highlighted (SCPs, advanced VPC patterns).
• Ticket drills: Stored transcripts/timelines from mock pager escalations; anonymized for interview use.

Gaps & next steps

• Earn Developer Associate and re-run the labs with IaC-first deployments.
• Pair with a real AWS Support engineer on a shadow shift to see how customer tickets differ from our simulations.
• Harden IAM knowledge (resource-level permissions, SCPs, org design) beyond what the internship covered.
• Turn the FFmpeg Lambda into a public tutorial once I replace the binary layer and add full test coverage.
• Build a “cost kill switch” pattern (Budgets → SNS → Lambda to tag/stop idle resources) to prove automated cleanup.
• Add synthetics against the capstone API (API Gateway → Lambda → DynamoDB) and publish results with dashboards.

Interview stories I reuse

• EC2 boot-loop fix: Found bad user-data and broken CloudWatch agent; rewrote idempotently, added alarms—shows calm debugging under pressure.
• S3 Access Denied: Used Policy Simulator + CloudTrail to prove missing Principal condition; fixed cross-account access—demonstrates systematic troubleshooting.
• Cost spike response: Identified idle NAT + orphaned EBS, tagged/terminated, set budgets/alerts—ownership + cost awareness.
• Capstone cold-starts: Measured FFmpeg cold-start impact, proposed container-based Lambda + signed URLs—trade-off thinking and next steps.
