In the modern engineering landscape, a resume is simply a list of unverified claims. Anyone can write "Proficient in WebGL" or "Experienced with CI/CD." The only metric that separates a senior engineer from a junior enthusiast is verifiable proof of work.

For the past quarter, I have adopted a strict discipline: I do not claim to know a technology until I have shipped a public, working URL that demonstrates it. This discipline forces me to confront the boring, difficult parts of software engineering—deployment, configuration, and environment isolation—that tutorials conveniently skip.

This post is a technical retrospective on my two most recent "Proof of Work" projects: AnimalSounds and the WebGPU Triangle Demo. Below is a detailed breakdown of the architecture, the specific failure points encountered, and the engineering lessons codified from each.

Case Study 1: AnimalSounds

The Artifact: Live Demo | Source Code The Stack: Vanilla JavaScript, Vite, GitHub Actions.

The Engineering Challenge: Sub-Path Routing in Static Environments

The goal was ostensibly simple: build a responsive soundboard. However, the true engineering challenge emerged during the deployment phase to GitHub Pages.

Modern frontend tooling (like Vite, Next.js, or Webpack) generally assumes the application is hosted at the Root Domain (e.g., https://myapp.com/). When an asset is referenced as /assets/sound.mp3, the browser resolves this to https://myapp.com/assets/sound.mp3.

GitHub Pages, however, hosts project repositories on a Sub-Path (e.g., https://username.github.io/repo-name/).

The Failure State

Upon the initial deploy, the application loaded the HTML, but the console was flooded with 404 Not Found errors for every JavaScript and CSS asset.

The browser was requesting: https://bradleymatera.github.io/assets/index.js

But the file actually existed at: https://bradleymatera.github.io/AnimalSounds/assets/index.js

This is a classic "Base Path" configuration error. A naive solution is to change all paths to relative (./assets/...), but this breaks client-side routing and makes the codebase brittle.

The Architectural Resolution

The robust solution required modifying the build pipeline to inject the base path dynamically based on the environment.

I modified the vite.config.js to accept a base argument.

// vite.config.js
import { defineConfig } from 'vite'


// [https://vitejs.dev/config/](https://vitejs.dev/config/)
export default defineConfig(({ command, mode }) => {
  return {
    // When building for production, assume the repo name is the base.
    // When in dev mode, assume root (localhost:3000/).
    base: mode === 'production' ? '/AnimalSounds/' : '/',
    build: {
      outDir: 'dist',
    }
  }
})

Furthermore, I had to ensure my automated deployment pipeline (GitHub Actions) was correctly triggering this production mode. By explicitly defining the environment in the CI yaml, I ensured that every commit to main resulted in a correctly routed build artifact.

The Lesson:

"Infrastructure awareness is not optional. You must configure your bundler (Vite/Webpack) to understand the physical location of its deployment, or your manifest will fail to resolve."

Case Study 2: WebGPU Triangle Demo

The Artifact: Live Demo | Source Code The Stack: TypeScript, WebGPU API, WGSL (WebGPU Shading Language).

The Engineering Challenge: The "Hello World" of Next-Gen Graphics

WebGPU is the successor to WebGL. While WebGL is a JavaScript wrapper around OpenGL (an older state-machine API), WebGPU is a modern, low-level API designed to map closely to Vulkan, Metal, and DirectX 12.

The challenge here was the sheer verbosity required to render a single triangle. In the HTML5 Canvas 2D API, drawing a triangle takes 3 lines of code. In WebGPU, it takes approximately 150 lines of boilerplate to set up the Render Pipeline.

The Implementation Details

To render this demo, I had to architect a specific pipeline of asynchronous hardware requests:

  1. Request Adapter: The code asks the browser for access to the physical GPU (Graphics Processing Unit).
  2. Request Device: The code asks for a logical instance to interact with that GPU.
  3. Configure Context: The HTML <canvas> element must be configured with a specific texture format (usually bgra8unorm) to match the screen's color space.

The Shader Challenge (WGSL)

The hardest part was writing the shaders. WebGPU does not use GLSL (the language used by WebGL). It uses WGSL (WebGPU Shading Language), a Rust-like language that is strictly typed.

I had to define a Vertex Shader that manually positioned the three points of the triangle in Normalized Device Coordinates (NDC):

// triangle.wgsl
@vertex
fn vs_main(@builtin(vertex_index) VertexIndex : u32) -> @builtin(position) vec4<f32> {
    var pos = array<vec2<f32>, 3>(
        vec2<f32>( 0.0,  0.5),  // Top
        vec2<f32>(-0.5, -0.5),  // Bottom Left
        vec2<f32>( 0.5, -0.5)   // Bottom Right
    );


    return vec4<f32>(pos[VertexIndex], 0.0, 1.0);
}

If I made a single type error in this shader—for example, passing a float where the pipeline expected a vec4—the application would crash silently with a GPU validation error.

The Lesson:

"Modern graphics programming requires a mental shift from 'drawing shapes' to 'configuring pipelines.' You are not telling the computer what to draw; you are building a machine that knows how to draw."

The "Micro-Lesson" Methodology

Why document these small projects with such rigor?

Cognitive science tells us that we retain information better when we attach it to a specific episode or struggle. By forcing myself to write down exactly one primary lesson per project, I create a searchable index of my own experience.

  • AnimalSounds is not just a soundboard; it is my reference for Vite Base Path Configuration.
  • TriangleDemo is not just a triangle; it is my boilerplate for WebGPU Device Initialization.

Keeping the Portfolio "Alive"

The final component of this system is the Update Date.

A portfolio is a living document. Technology rots. A WebGPU demo written in 2023 might not compile in 2025 because the API specification changed. By prominently displaying Updated: 2025-06-01 at the top of my documentation, I signal to the reader (and to recruiters) that this code is maintained, current, and verified against today's browser standards.

If you are building a portfolio, stop listing languages you read about once. Build a thing. Break the thing. Fix the thing. Then write down exactly how you fixed it.

That is the only proof that matters.
